Provide multi-spectral data support for ecological protection, resource management, urban and rural planning and disaster response, etc. lt is widely applied in fields such as precision agriculture management, identification of plant diseases and pests, crop yield prediction, forestry resource investigation, grassland ecological assessment and urban greening planning, land use classification, wetland protection monitoring, water environment management, mine ecological restoration, and disaster emergency assessment.
Product Parameters
|
Product Parameters |
|
|
Imaging Method |
Push-Broom / Video Imaging |
|
Spectral Band |
Visible Camera / Infrared Camera / Spectral Camera |
|
GSD |
≤ 0.1m @ 5Km |
|
Swath Width |
Push-Broom: ≥ 800m @ 1km Video: ≥ 800m×600m @ 1km |
|
Quantization Bits |
8bit / 10bit |
|
Static Modulation Transfer Function (MTF) |
≥ 0.12 |
|
Signal-to-Noise Ratio (SNR) / NETD |
Typical ≥ 30dB / 50mK |
|
Supply Voltage |
12V |
|
Communication Interface |
RS232 / RS422 / I2C |
|
Data Transmission Interface |
SDI, CameraLink, USB, Ethernet Port |
|
Weight |
≤ 300g |
* Specific specifications can be customized
