Characterized by multi-sensor fusion, AI data analysis, etc. It is applicable to space target monitoring (Orbital object tracking, threat identification), environmental perception(Space weather monitoring, electromagnetic spectrum analysis), and safety early warning(Collision warning, attack alert).
Product Parameters
Space Situation Awareness Camera Configuration Scheme
|
Code |
Configuration |
Function |
|
SSAC |
Camera SuperScan Camera |
High-sensitivity low-threshold space target imaging functionHigh-elevation target staring observation function coordinated with satellitesGround image super-resolution processing function |
|
SSAC-Pro |
Camera overscan turntable |
High-sensitivity low-threshold space target imaging functionGround image super-resolution processing functionLarge-range sky survey functionSatellite attitude stability compensation functionAutonomous high-elevation target staring observation function |
|
SSAC-Max |
Camera overscan mechanism turntable on-board intelligent processing |
High-sensitivity low-threshold space target imaging functionLarge-range sky survey functionSatellite attitude stability compensation functionAutonomous high-elevation target staring observation functionOn-orbit real-time image super-resolution processing functionOn-orbit real-time target identification and early warning function |
Product Parameters
|
Detection Capability |
Equivalent 10th-magnitude space debris (exposure time 20ms),Equivalent 15th-magnitude space debris (exposure time 2s), SNR ≥ 5 |
|
Angle Measurement Accuracy |
8" |
|
Field of View (FOV) |
≥ 10°×10° |
|
Spectral Range |
450nm~800nm |
|
Modulation Transfer Function (MTF) |
≥ 0.2 |
|
Energy Concentration |
≥ 0.8@1 pixel |
|
Resolution |
≥ 4K×4K |
|
Frame Rate |
≥ 10fps |
|
Focusing Range |
±1mm |
|
2-Axis Gimbal |
Azimuth: -170°~+170°, Elevation: 10°~40°;Maximum angular velocity 4°/s, Positioning error ≤ 0.01°;Measurement accuracy ≤ 2" |
|
Intelligent Processing Unit Recognition Rate / False Alarm Rate |
Detection rate ≥ 95%, False alarm rate ≤ 5% |
|
Centroid Positioning Error of Intelligent Processing Unit |
≤ 0.7pixel |
|
Overall Dimensions |
Camera main body: 300mm×50mm×150mmControl unit: 150mm×150mm×80mmIntelligent computing unit: 150mm×150mm×80mm |
|
Weight |
Camera main body + turntable: 5kgControl unit: 1.5kgIntelligent computing unit: 1.5kg |
|
Power Consumption |
Imaging: 20wImaging + follow-up: 30wImaging + tracking + intelligent calculation: 80wThermal control: 7w |
|
On-orbit Lifespan |
≥ 5 years |
|
Reliability |
≥ 0.9 |
* Specific specifications can be customized
