Compact Space Remote Sensing Camera

GSD

≤1m@500km

≤1.5m@500km

≤2m@500km

≤4m@500km

Spectral Bands

RGB：

Blue：400 ~ 520 nm

Green：480 ~ 600 nm

Red：590 ~ 700 nm

PAN：450 ~ 800 nm

B1：450 ~ 520 nm

B2 ：520 ~ 590 nm

B3 ：630 ~ 695 nm

B4：770 ~ 890 nm

Swath Width

Push-broom: 7.8 km

Video: 7.8×5.6 km

Push-broom: 11.6 km

Video: 11.6×8.4 km

Push-broom: 15 km

Push-broom: 16 km

Imaging Mode

Push-broom + Video Imaging

Push-broom Imaging

Static Modulation

Transfer Function (MTF)

≥ 0.12

Signal-to-Noise Ratio

(SNR)

Typical: ≥ 30 dB

Supply Voltage

10~13V

Communication

Interface

CAN2.0

Data Transmission Interface

CXP/CameraLink/Ethernet Port

Weight

≤ 20kg

≤ 12kg

≤ 6kg

≤ 2kg

Size

540×520×840 mm

310×300×580 mm

210×180×400 mm

100×100×350 mm

Power Consumption

Short-term: ≤ 30 W

Long-term: ≤ 20 W

Short-term: ≤ 25 W

Long-term: ≤ 15 W

Short-term: ≤ 22 W

Long-term: ≤ 12 W

Short-term: ≤ 20 W

Long-term: ≤ 10 W

Service Life

3~5 years

3~5 years

3~5 years

3~5 years
