The first choice for high-precision applications. Ground GSD of 0.25 m panchromatic/1m multi-spectral @ 500 km, the Swath width is more than 10 km. The spectral range covers visible light to near-infrared and the comprehensive indicators are internationally leading.
High-precision data is widely used in 3D real-time imaging, smart transportation, precision agriculture, detailed land surveys, digital twins, and other fields.
Product Parameters
|
Product Parameters |
|
|
Spectral Bands (Customizable: 1+8, 1+16 bands) |
1 Panchromatic + 4 Multispectral Bands: PAN: 450 ~ 800 nm B1: 450 ~ 520 nm B2: 520 ~ 590 nm B3: 630 ~ 695 nm B4: 770 ~ 890 nm |
|
GSD |
Panchromatic:0.25m@500kmorbit Multispectral:1.0m@500kmorbit |
|
Swath Width |
≥ 10.5km @ 500km orbit |
|
Imaging Mode |
TDI Push-Broom |
|
Static Modulation Transfer Function (MTF) |
Panchromatic: ≥ 0.15 Multispectral: ≥ 0.25 |
|
Signal-to-Noise Ratio (SNR) |
Typical: 35 dB |
|
Data Rate |
21 Gbps |
|
Supply Voltage |
26 ~ 45V |
|
Communication Interface |
CAN2.0 |
|
Data Transmission Interface |
CXP |
|
Size |
1800×1500×2800 mm |
|
Weight |
300 Kg |
|
Power Consumption |
Short-term: ≤ 320 W Long-term: ≤ 400 W |
|
Service Life |
5 years (reliability: 0.94) |
* Specific specifications can be customized
